ROHN / American 25G TOWER SECTION TOP CAP R-25AG1
ROHN/American 25G TOWER SECTION TOP CAP - 25AG1 |
DO NOT ORDER ONLINE- CALL JOHN FOR PRICING AND SHIPPING
CALL JOHN FOR DETAILS AT 3523-237-3811
ROHN / American25AG1 9 Foot 3 inch (1.66 inch Outside Diameter) Tower Top Cap Section
consists of 16 gauge walls with 5 bays of bracing and swaged, double-bolted connections. The Pinnacle of this Section is Capped with a 1-1/4 inch STD Pipe (1.66 inches O.D.) threaded as 1-1/4 inch N.P.T., protruding 10.00 inches above apex of side rails.
| 25AG1 | |||
|---|---|---|---|
| QUANTITY | PART NUMBER | DESCRIPTION | |
| 1 | 25AG1 | Top Cap Tower Section - 1.66" O.D. | |
| 1 | 25AJBK | Bolt Kit for (25G) Top Tower Section | |
This section is used to top off the 25G tower. The 25AG1 is available in the standard 9 foot 3 inch section length. This tower uses double bolted joints which are proven to be the best method of joining tower sections for sturdiness and dependability. Featuring a 12-1/2" equilateral triangular design, the 25AG is constructed of extra heavy duty 1-1/4" steel tubing side rails with continuous solid steel rod bracing. Each 9' section is shipped containing all required nuts and bolts inside one leg. The 25G tower can be used in guyed, self-supporting or bracketed configurations according to specifications in the ROHN catalog. Consult ROHN Catalog Links at Footer Section below for 25G Tower Details.
Note: Due to unreliable supply chains and constant price variations, we offer Rohn and American Tower. The two are interchangeable and are hard to tell apart, Ask John what he he in stock.
Details:
Hot Dip Galvanized
Double Bolted Joints
Zig-Zag Rod Bracing
1-1/4" Steel Tubing
Side Rails
12-1/2" Equalateral
Triangular Design
Can be used in:
Guyed Self Supporting
Bracketed Config.s
