Televes 108381 8 Bay Multi-Directional Dual Market Outdoor Antenna w/ Standard Professional Installation

Televes 108381, 8 Bay Dipole Array Amplified Antenna, hi-VHF/UHF, 5G/LTE Filtered, Multi-directional Dual Market Antenna with Standard Professional Installation

Professional installation available in Central Florida only—call for availability in your area!

• 2-Panel BOSS MIX antenna with bowties specifically designed to pick up hi-VHF and UHF stations .
• - Built in dual band preamplifier with independent and automatic high-VHF and UHF regulation
• - Built-in FM and 5G/LTE cell phone filtering to prevent interference from affecting TV reception.
• - Four integrated hi-VHF dipoles for hi-VHF performance unseen on any 8-bay dipole array to date
• - One of the panels can be rotated, making this antenna a great solution for situations where signals come from different locations.

The stacked-dipole panel antenna contains 8 dipoles, separated in such a way that their effects multiply, which produces a high gain and exceptional bandwidth antenna. The flat reflectors are equipped with 12 elements. This antenna is designed for situations where the signals come from different directions, but it is also an excellent choice when the signals are all in a single direction. Assembly required.

• Built with corrosion-resistant aluminum and ABS plastic for high weather resistance and a long service life.

• The mast-mounting hardware utilizes Zamak to provide sturdiness and stability in adverse weather conditions
• Designed and manufactured in Europe where the products undergo the most stringent quality controls
• Includes preamp with automatic gain control (AGC) to adjust for differing signal strengths, so strong stations won't overwhelm weaker stations.

• Includes a balun to provide a 75Ω coax output

• Size: 31.5" H x 52" W x 6.5" D

In addition to receiving HDTV signals, this antenna is also capable of receiving 4k ultra high definition stations (aka NextGen TV / ATSC 3.0 / UHD). Viewing 4k UHD also requires a TV capable of receiving 4k UHD signals and TV station(s) broadcasting in 4k UHD.

Manual

Declaration of Conformity

keywords HD, UHDTV, hi def

Includes: Sky Blue SB22 Antenna, Sky Blue SB51 Amplifier, 2-10F 18G Sledged Mast Poles w/ 4" Stand-Off Bracket and 50 FT Belden RG-5 Coax Cable w/ 4 PPC EX6PLUS RG-6 Snap & Seal Outdoor Compression Connectors, 6 Zip Ties, and 10 Cable Clips.

AND STANDARD INSTALLATION TO ONE TV!
