Televes 560483 Dual Input Antenna Preamp
Televes 560483 Dual Input Antenna Preamp, Coaxial F-fitting Connections, Automatic Gain Control (AGC), 5G filtered
Televes Corporation® 560483 Mast Amplifier with BOSS and “F” Power Supply Kit
The ultimate signal! The Mast Amplifier and Power Supply Kit filters and amplifies television signals coming from up to (2) antennas. It optimizes LTE band rejection up to 36 channels (repack ready), is equipped with (2) inputs for amplification on Low VHF, High VHF, and UHF bands, all powered though the output coaxial cable.
Features
This kit is complemented with a domestic 12 V-power supply unit (220mA) included in the installation. The PSU powers equipment through the input coaxial cable while allowing the transmission of the TV signal, in addition to being UL certified (US plug). Best of all, it allows the installer to adapt the output level to the necessary characteristics of the distribution network.
Televes Corporation®
This kit is complemented with a domestic 12 V-power supply unit (220mA) included in the installation. The PSU powers equipment through the input coaxial cable while allowing the transmission of the TV signal, in addition to being UL certified (US plug). Best of all, it allows the installer to adapt the output level to the necessary characteristics of the distribution network.
Televes Corporation®
Televes is a company belonging to Televes Corporation. Televes Corporation groups more than 20 companies which all work to achieve the common objective of design and produce the best equipment used to equip homes, buildings and cities with optimum telecommunication infrastructures.
| Inputs/Bands: | 2 x (Low VHF / High VHF/UHF) |
| Frequency Margin: | 54-88MHz / 174-216MHz / 470-608MHz |
| Gain: | 18 dB Low to Mid Range / 27 dB High Range |
| Automatic Gain Adjustment Range: | 0-15dB |
| Input level Regulation Margin: | 0-20 Manual dB |
| Output Margin: | DIN45004B: 43dBmV Low to Mid range / 47dBmV High Range, EN 60728-3 (IMD3 2CH-35dB: 51dBmV Low to Mid Range / 55dBmV High Range |
| Power Supply: | 12Vdc / 50mA |
| Max Current Through Inputs: | Off: 0 mA, On: 70 mA |
| Operating Temperature: | +23-113°F |
| Protection Index: | 23IP |
| Frequency Margin: | 5-862Mhz |
| Through Loss (typ.): | 1 Out: Main-1.5 dB / Aux-0dB, 2 Out: Main-4dB / Aux-4 dB |
| Output Interstage Equalizer: | 12±1.5V |
| Max Output Current: | 220V |
| Min Output Current: | 30mA |
| Powering: | 108-32V~ / 50-60Hz |
| Max. Consumption: | 65mA~ / 3.6W |
| Protection Index: | 20IP |
| Operating Temperature: | 14-113°F+ |
