The DAT BOSS LR Mix is an state of the art long range over the air TV antenna that automatically adapts its gain in real time to optimize the reception of television signals, ensuring the optimum level of signal is delivered at all times. This latest repack-ready version has been completely redesigned from the ground up for the new US broadcast frequencies, significantly improving gain and range over previous generations, filtering any interfering 5G signals above 608MHz, and providing independent amplification for the VHF and UHF bands.
The DAT BOSS LR Mix is able to receive very weak distant signals while at the same time avoiding overload caused by very strong signals. This is a very high gain directional antenna designed to offer stable and high quality reception of UHF and high VHF signals only (RF channels 7-36) in challenging long-range and fringe receiving scenarios despite continuous changes in weather and transmitting conditions thanks to its exclusive and intelligent built-in TForce amplifier. The Televes proprietary stacked triple boom design ensures market leading raw gain while still maintaining a compact and install friendly form factor. No additional preamplifier purchase is required as the antenna includes a best-in-class very low-noise TForce preamplifier built in right at the dipole with automatic gain control, plus FM and cellphone signal filtering adapting to any installation situation.
A low-consumption UL-listed power supply is included providing two outputs for convenient distribution to additional TV sets. Not only do industry experts rave about the DAT BOSS LR Mix exceptional long range performance and market leading gain but also the unparalleled manufacturing quality using only the finest materials (aluminum, stainless steel, ABS plastic) ensuring years of trouble free operation in the most challenging environments. It ships as a compact package including the tools needed for assembly. The DAT BOSS LR Mix is your best option for a long range high gain antenna with automatic gain control and precise filtering to ensure the best possible reception of High VHF and UHF signals under the most challenging circumstances.
Televes transitions from the traditional silicon era into a new era of electronic component design, allowing integrated circuits to be precisely manufactured for microwave frequency bands. Utilizing “State of the Art” MMIC technology TForce is manufactured using semiconductor compounds such as gallium arsenide (GaAs), providing the resulting products with unparalleled features and performance
Televes has reinvented the antenna concept. Until now, an antenna was just the reception component of a TV installation in which gain and directivity were the main features. The introduction of a smart device like BOSS provides the antenna with the capacity to receive very weak signals without the risk of being affected by very strong signals, the result is a dynamic balance between weak and strong signals that provides optimum signal levels at all times: the "dynamic range" concept turns out to be the most outstanding among quality parameters.
The creation of TForce with BOSS technology using MMIC components is an extraordinary milestone in the optimization of the dynamic range. The technology that allowed the reception of lost signals from distant satellites is now allowing the enhancement of the coverage range in DTT installations.
Bands |
|
||||||||
---|---|---|---|---|---|---|---|---|---|
Frequency range | MHz |
|
|||||||
Channels |
|
||||||||
|
|
||||||||
Gain | dBi |
|
|||||||
Output level |
|
||||||||
Powering |
|
||||||||
Max. current |
|
||||||||
Beamwidth | º |
|
|||||||
F/B ratio | dB |
|
|||||||
Wind load (@130Km/h) | N | 182.4 | |||||||
Wind load (@150Km/h) | N | 250.8 |
*1 The gain is automatically adjusted according to the level of output
*2 The gain is automatically adjusted according to the level of output
